end-face cleaner

shm-503（handi mate^tm）
this newly added handimate with cleaning cloth provides further usability and reliability to the users. it enables to clean even sc/apc step ferrule connector thanks to the high durability cleaning cloth.
	handy and high performance cleaner that fits in your hand and achieves cleaning more than 500 times just one sliding motion enables to remove contamination such as dust or oil on optical connector end-face connector to be set on guide holder enables stable and even cleaning result always shm-503 enables to clean duplex lc and duplex mu connectors in addition to simplex sc,fc,st,lc and mu connectors.

part no.	shm-503
application	clean male connector endface
dimension	h110×w68×d28mm (cap opened)
weight	80g
operation	slide type
life	more than 500 times
applicable connector	sc, fc, st, lc, mu for pc and apc duplex lc/pc,duplex mu/pc

shm-501(handi mate^tm)
	handy and high performance cleaner that fits in your hand and achieves cleaning more than 500 times just one sliding motion enables to remove contamination such as dust or oil on optical connector end-face connector to be set on guide holder enables stable and even cleaning result always

part no.	shm-501
application	clean simplex connector tip
dimension	h110 x w68 x d28mm (cap opened)
weight	75g
operation	slide type
life	more than 500 times
applicable connector	sc, fc, st, lc, mu
