cl-1000
	video microscope system ideal for installation site enables the user to inspect mounted connector endface from the other side of adapter connectable to a portable monitor, pc through usb and stationary monitor easy adapter replacement allows the microscope to inspect a wide range of connector types
	cl-1000
	dimension(mm)/weight(kg) (scope)	175 x φ32 / 0.16
	dimension(mm)/weight(kg) (monitor)	105 x 95 x 45 x / 0.45
	magnifications	180 x (3.5"lcd)
	light source	blue led
	power	110-220v 50/60hz 9.6v ac/dc adapter internal rechargeable battery
	battery life	4 hours 1 hours for charging
	monitor	3.5"lcd
	optional items
	usb video capture device	available
	connector attachment	2.5mm ferrule, fc, sc, 1.25mm ferrule, mu, lc, mtp, mpo,mt-rj, mt ferrule
	bunlkhead attachment	fc, sc, mu, lc, st, mtp, mpo, mt-rj
sim-200/400
	handy type microscope operated with three aaa batteries two magnification types are available (200x or 400x) high intensity white led for clear and enhanced vision detachable φ2.5mm ferrule adapter is equipped as standard accessory other connector adapters are also available as optional. also laser safety filter is equipped for eye protection
